2019 ATC QUEST 8.5X28 Car / Racing Trailer….STOCK# AT-215029 – $32495

Description

2019 ATC QUEST 8.5X28 Car / Racing Trailer….STOCK# AT-215029

GVWR- 9990
SHIPPING WEIGHT- 4424
BASE MODEL
QSTAB8528+0-2T5.2K
PACKAGES
PACKAGE – CAR HAULER – CH 405
FRAME
AXLE – 5200LB – TORSION – EZ LUBE HUBS – ELECTRIC BRAKES
AXLE SPACING – SPREAD AXLE
ALL TUBE CONSTRUCTION
COUPLER – A-FRAME – 2-5/16IN – 10,000LB
CROSS MEMBERS – FLOOR – 16IN O/C
CROSS MEMBERS – ROOF – 16IN O/C – 1IN X 3IN
CROSS MEMBERS – WALL – CS – 16IN O/C – 1IN X 1.5IN
CROSS MEMBERS – WALL – RS – 16IN O/C – 1IN X 1.5IN
FLOOR DESIGN – BEAVERTAIL
FRAME – 8IN
FRAME – FULL PERIMETER – ALUMINUM
FRAME PROTECTION – SKID PLATES
FRONT DESIGN – FLAT
JACK – TONGUE – TOP WIND – 5000LB – ZINC
TIRE/WHEEL – ST225/75R15/LRE – RADIAL ON ALUMINUM – W/STAINLESS STEEL LUGNUTS
SPARE TIRE COMPARTMENT – IN FLOOR
TONGUE – EXTENDED TRIPLE TUBE – 12IN
TRUCK PLUG – 7 WAY – BUMPER PULL
BACKER – AL – TUBE 1IN X 3IN – SPARE TIRE
EXTERIOR
AWNING RAIL
EXTERIOR ALUMINUM – STANDARD COLOR
COLOR: BLACK
EXTERIOR FASTENER – SCREWLESS
EXTERIOR ALUMINUM THICKNESS – .040
4 FENDERETTES – AL – POLISHED
GRAVEL GUARD – ATP – 24IN – WITH J RAIL
ROOF – ONE PIECE – ALUMINUM
SKIRTING – PERIMETER SKIRTING W/ REVERSE BEAVERTAIL
TRIM – VERTICALS – FRONT & TOP RADIUS – STAINLESS STEEL W/ CAST CORNERS – POLISHED
TRIM – SPOILER – REAR – COLOR MATCHED W/ 3 LED LIGHTS
TRIM – VERTICALS – REAR – STAINLESS STEEL
TRIM – RUB RAIL – UPPER – ALUMINUM – 4IN
TRIM – RUB RAIL – LOWER – ALUMINUM – 7IN
2 VENT – ROOF – MANUAL – 14IN
DOORS
DOOR – REAR RAMP – PREMIUM – CONTINUOUS ALUMINUM HINGE – 2400LB RATED MAX LOAD – 4000LB VEHICLE LOAD
RAMP DOOR EXTERIOR – REAR – COLOR MATCHED
TRANSITION FLAP – ALUMINUM – EXTRUDED – 16INL
RAMP DOOR FLOORING – REAR – ALUMINUM – EXTRUDED
DOOR LATCH – PADDLE – STAINLESS STEEL
DOOR – ENTRANCE – 405 SERIES – 48IN X 78IN – FMVSS LOCK
STEP – SLIDE IN/OUT – ALUMINUM – 48IN
DOOR – ESCAPE – PREMIUM – 88IN X 72IN – TOP HINGE – FMVSS LOCK – REMOVABLE WHEEL WELL
DOOR – GENERATOR – 405 SERIES – 36IN X 36IN
INTERIOR
INTERIOR HEIGHT – 7.0FT
CABINET CONFIGURATION – B0-100INW – LB112
CABINET COLOR: BLACK
COUNTERTOP – ALUMINUM – FOR LOWER CABINET
INTERIOR CEILING – SCREWLESS ALUMINUM
COVE COLOR: BLACK
INSULATION – CEILING – EPS – 1IN – R-3
INTERIOR WALLS – SCREWLESS ALUMINUM
WALL COLOR: POLAR WHITE (STANDARD)
INSULATION – WALLS – EPS – 1IN – R-3
FLOORING – ALUMINUM – EXTRUDED
4 D-RINGS – SWIVEL – 6000LB – RECESSED
2 WHEEL BOX – SMOOTH AL
ELECTRICAL
BATTERY – 12V AGM (930 CA, 775 CCA)
USED FOR: CH405 PACKAGE
BREAKER BOX – 50 AMP – 120V ONLY – 60 AMP CONVERTER – 12V FUSE PANEL – INTELI-POWER UNIT
SWITCH – POWER CUT-OFF – MANUAL – 12V
POWER INLET – MOTORBASE – 50A – W/ SHORE CORD – 25FT
4 LIGHT – CLEARANCE – LED – 12V – AMBER – LOWER
4 LIGHT – CLEARANCE – LED – 12V – AMBER – UPPER
2 LIGHT – CLEARANCE – LED – 12V – RED – LOWER
7 LIGHT – CLEARANCE – LED – 12V – RED – UPPER
LIGHT – TAILLIGHT – SLIMLINE – LED – 12V – RED
LIGHT – TAILLIGHT – SLIMLINE – LED – 12V – RED
2 LIGHT – SCENE – LED – HIGH OUTPUT – 12V – NON RECESSED – 7IN X 3IN – CHROME BEZEL
SWITCH – WALL – 12V
3 RECEPT – INTERIOR – 120V – 15A
RECEPT – EXTERIOR – 120V – 15A – GFI PROTECTED
LIGHT – PUCK – LED – 2.75IN – 12V – NON RECESSED
SWITCH – WALL – 12V
LIGHT – RECTANGULAR – LED – 18IN – 12V – RECESSED – W/ TRIM RING
SWITCH – WALL – 3 WAY – 12V
SWITCH – RELAY – 12V – 30A
SWITCH – WALL – 12V
HEATING & AIR CONDITIONING
A/C PREP – BRACE & WIRE
